| Part number |
5412053616 |
| Model |
FW-6PH-1 BF N |
| Handle type |
Pistol |
| Square drive |
3/8″ |
9,5 mm |
| Square drive |
9,5 mm |
3/8 |
| Working Torque Range (fwd) |
24 – 45 Nm |
18 – 33 |
| Maximum Torque (fwd) |
50 Nm |
37 ft.lbs |
| Free speed |
9000 rpm |
| Net weight |
1.35 kg |
2.98 lb |
| Length |
147 mm |
5.79″ |
| Actual air consumption |
5.8 l/s |
12.4 cfm |
| Min. hose size |
9.5 mm |
3/8″ |
| Sound pressure |
95 db(A) |
| Sound Power |
106 db(A) |
| Vibration α (ISO-28927-2) |
4.5 m/s² |
| Vibration K (ISO-28927-2) |
1.4 m/s² |
| Socket retainer |
Pin (BF-Anvil) |
| Clutch type |
Double hammers |
| Bolt size |
M8 |
5/16 |
