| Model |
CP8818 |
|
| Part number |
8941088189 |
|
| Ah |
1 1/2 Ah |
|
| Battery type |
1,5Ah 12V Lithium-ion |
|
| Battery voltage |
12 V |
|
| Blows per minute |
3000 |
|
| European Directives |
Machinery (2006/42/EC), RoHs (2011/65/EU), EMC (2014/30/EU)Machinery (2006/42/EC), RoHs (2011/65/EU), EMC (2014/30/EU) |
|
| European Sound standard |
EN 62841 |
|
| European Standards |
EN 62841-1:2015; EN62841-2-2:2014, EN 55014-1:2017, EN 55014-2:2017, EN50581-1:2012 |
|
| Free speed |
2000 rpm |
|
| Height |
185.3 mm |
7.29 “ |
| Length |
161 mm |
6.3 “ |
| Max torque |
115 Nm |
85 ft.lbs |
| Max. ambient operating temperature |
50 °C |
122 °F |
| Max. ambient storage temperature |
40 °C |
104 °F |
| Maximum Torque (reverse) |
115 Nm |
85 ft.lbs |
| Min. ambient operating temperature |
-18 °C |
-0.4 °F |
| Min. ambient storage temperature |
0 °C |
32 °F |
| Net weight |
1.09 kg |
2.4 lb |
| Recommended max. ambient charging temperature |
38 °C |
100 °F |
| Recommended min. ambient charging temperature |
10 °C |
50 °F |
| Sound Power |
98 db(A) |
|
| Sound pressure |
87 db(A) |
|
| Sound uncertainty |
3 db(A) |
|
| Square drive |
1/4 Hex. “ |
|
| Vibration |
4.8 m/s² |
|
| Vibration ISO |
ISO-28927-2 |
|
| Vibration uncertainty (K) |
1 1/2 m/s² |
|
| Weight without battery |
0.9 kg |
1.98 lb |
| Width |
55.5 mm |
2.18 “ |
| Working torque Range |
23 – 97 Nm |
16 – 71 ft.lbs |
